Elastic fabric mask machine

Power supply:AC 380V 60HZ  3phase

Power:12KW

Design speed:300pcs/min

Optimum speed:200pcs/min

Dimension:2200*2100*1500mm

Weight：1800KG

 Configuration:

Ultrasonic : 3sets (Taiwan King sonic )

Motor:   1    TaiWan “YongKun”

Touch screen:    1    TaiWan “Delta”

Inverter:    1    TaiWan “Sunfar”

PLC:   1    TaiWan “Delta”

Correction device:          4sets

Load cell:     8pcs

servo-motor  :  8sets(delta )

Driving part : Timing Belt & pulley : HTD-5M

Low-voltage electrical: 1   delixi

Cylinder : 8pcs

Suction device: 2sets (there’s some noise )

Vacuum cutter roll (chip removal system): similar as your photo and video , but not same

Installation and Test : customer pay the Round  flight tickets, Visa, Accommodation and Meal

Delivery time: 2months

Payment Term:30% Advance Payment BY T/T.Remain 70% Payment By T/T before we send the machine to shanghai port.

Packing:wooden package
